Output
Output power capacity: 500 Watts / 750 VA
Max Configurable Power (Watts): 500 Watts / 750 VA
Nominal Output Voltage: 230V
Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage
Output Voltage Distortion: Less than 5% at full load
Output Frequency (sync to mains): 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
Other Output Voltages: 220, 240
Topology: Line Interactive
Waveform type: Sine wave
Output Connections: (4) IEC 320 C13 (Battery Backup)
Transfer Time: 2ms typical

Input
Nominal Input Voltage: 230V
Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections: IEC-320 C14
Cord Length: 1.83 meters
Input voltage range for main operations: 160 - 286 V
Input voltage adjustable range for mains operation: 151 - 302 V
Number of Power Cords: 1
Other Input Voltages: 220, 240

Batteries & Runtime
Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
Typical recharge time: 3 hour(s)
Replacement Battery: APCRBC123
RBC Quantity: 1
Battery Volt-Amp-Hour Capacity: 168
Runtime: View Runtime Graph View Runtime Chart
Efficiency: View Efficiency Graph

Communications & Management
Interface Port(s): RJ-45 Serial, SmartSlot, USB
Control panel: Multi-function LCD status and control console
Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
Emergency Power Off (EPO): Optional
Available SmartSlot Interface Quantity: 1

Surge Protection and Filtering
Surge energy rating: 459 Joules
Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449
