DeepCool PQ1000G WH 1000W Gamer Storm 80+ Gold/Cybenetics Fully Modular ATX Power Supply 120mm Fan, Japanese Capacitors, DC to DC, ATX12V V3.1, R-PQA00G-FD1W-JGAU-V1
DeepCool PQ1000G WH 1000W Gamer Storm 80+ Gold/Cybenetics Fully Modular ATX Power Supply 120mm Fan, Japanese Capacitors, DC to DC, ATX12V V3.1, R-PQA00G-FD1W-JGAU-V1
SKU:L-PSD-PQ1000G-GS-WH
Regular price
$177.00
Regular price
Sale price
$177.00
Unit price
per
- Dispatched same/next business day
- Australian stock and warranty
- Perth pickup may be available (2-4 days)
Couldn't load pickup availability
Technical Spec
Total Output1000W
TypeATX12V V3.1
Product Dimensions15014086mm (W x L x H)
Efficiency certification80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Fan Size12012025mm (W x L x H)
Fan BearingFDB (Fluid Dynamic Bearing)
TopologyActive PFC + Half Bridge SRC LLC + DC to DC
CapacitorsFull Japanese Electrolytic Capacitors
Power Good Signal100-150ms
Hold Up Time16ms Full load
Efficiency90% Under Typical Load(50% Loading)
ProtectionOPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature0-40C
RegulatoryEAC
Erp RegulationErP 2013
Environment ProtectionEAC
MTBF100,000 Hours
View full details
Total Output1000W
TypeATX12V V3.1
Product Dimensions15014086mm (W x L x H)
Efficiency certification80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Fan Size12012025mm (W x L x H)
Fan BearingFDB (Fluid Dynamic Bearing)
TopologyActive PFC + Half Bridge SRC LLC + DC to DC
CapacitorsFull Japanese Electrolytic Capacitors
Power Good Signal100-150ms
Hold Up Time16ms Full load
Efficiency90% Under Typical Load(50% Loading)
ProtectionOPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature0-40C
RegulatoryEAC
Erp RegulationErP 2013
Environment ProtectionEAC
MTBF100,000 Hours
Description
Technical Spec
Total Output1000W
TypeATX12V V3.1
Product Dimensions15014086mm (W x L x H)
Efficiency certification80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Fan Size12012025mm (W x L x H)
Fan BearingFDB (Fluid Dynamic Bearing)
TopologyActive PFC + Half Bridge SRC LLC + DC to DC
CapacitorsFull Japanese Electrolytic Capacitors
Power Good Signal100-150ms
Hold Up Time16ms Full load
Efficiency90% Under Typical Load(50% Loading)
ProtectionOPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature0-40C
RegulatoryEAC
Erp RegulationErP 2013
Environment ProtectionEAC
MTBF100,000 Hours
Total Output1000W
TypeATX12V V3.1
Product Dimensions15014086mm (W x L x H)
Efficiency certification80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Fan Size12012025mm (W x L x H)
Fan BearingFDB (Fluid Dynamic Bearing)
TopologyActive PFC + Half Bridge SRC LLC + DC to DC
CapacitorsFull Japanese Electrolytic Capacitors
Power Good Signal100-150ms
Hold Up Time16ms Full load
Efficiency90% Under Typical Load(50% Loading)
ProtectionOPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature0-40C
RegulatoryEAC
Erp RegulationErP 2013
Environment ProtectionEAC
MTBF100,000 Hours
