Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA PR1KCN40

Technical Data
Mounting type
M6 Screw or Adhesive

Enclosure material
PC/PC+ABS

UV resistant


Cable length
3000 mm

Weight
450 g

Operating temperature
-40 C +80 C

Operating humidity
90 %

Ingress Protection Rating
IP67

RoHS compliant


5G MOBILE MIMO ANTENNA
Frequency range
600 960, 1427 2700, 3300 4200, 4400 5000 MHz

Polarisation
Linear

Radiation pattern type
Omni-directional

Gain
4 dBi

V.S.W.R
2.5

Impedance
50

Connector type and count
4 x SMA Male

Cable type
4 x LMR100

GNSS ANTENNA
Frequency range
1559 1610, 1164 1189 MHz

Polarisation
RHCP

Radiation pattern type
Directional

Gain
2 dBi

LNA Gain
17 2 dB

LNA noise figure
2 dB

V.S.W.R
2

Impedance
50

Supply voltage
3 5 VDC

Current consumption
15 mA

Connector type and count
1 x SMA Male

Cable type
1 x LMR100
