TP-Link ER701-5G Outdoor Omada 5G Gateway with Dual Nano SIM Support, PoE Power Input, 2.5G Ethernet Port, Enterprise Routing, VLAN, Firewall ER701-5G-Outdoor

TP-Link ER701-5G Outdoor Omada 5G Gateway with Dual Nano SIM Support, PoE Power Input, 2.5G Ethernet Port, Enterprise Routing, VLAN, Firewall, and Omada Cloud Management


Device


Outdoor 5G Gateway / Router

Dual
Nano SI
PoE powered


Omada-managed


Cellular 5G NR


Bands:

n1 / n3 / n5 / n7 / n8 / n20 / n26 / n28 / n38 / n40 / n41 / n75 / n76 / n77 / n78


Frequencies:

700 / 800 / 850 / 900 / 1500 / 1800 / 2100 / 2300 / 2500 / 2600 / 3500 / 3700 MHz


SA:

7.01 Gbps / 1.25 Gbps


NSA:
4.5 Gbps / 730 Mbps


Cellular 4G LTE


FDD:

B1 / B3 / B5 / B7 / B8 / B20 / B26 / B28 / B32


TDD:
B38 / B40 / B41 / B42 / B43


Speed:
1.6 Gbps / 211 Mbps


Cellular 3G


WCDMA:

B1 / B5 / B8


SIM


1 Dual Nano SIM slot


Failover supported


Ethernet


1 2.5G RJ45


10 / 100 / 1000 / 2500 Mbps


PoE:


802.3at (4257 V, 0.6 A)


Passive 48 V


Wireless (Local)


2.4 GHz only


802.11 b / g / n


150 Mbps max


WPA / WPA2-Personal


1 SSID


TX power control


Auto channel selection
Routing / Switching


Static routing


OSPF (Standalone)


Bridge VLAN


802.1Q VLAN


Multi-Net interfaces


NAT / Firewall


Multi-Net NAT


Virtual server


Port triggering


NAT-DMZ


ALG: FTP / SIP / IPSec / PPTP / H.323


UPnP


Stateful ACL
Storage / Memory


4 GB eMMC


2 GB LPDDR4x
Power

Max consumption:
15.3 W
Physical

Dimensions:
183 110 36 mm


Wall / pole / window mount


Waterproof kit included

Warranty Period: 3-Year
